Eclipse Servo Drive Pricing
Model |
Description |
Photo |
Datasheet |
Price (100-pc/yr qty) |
|---|---|---|---|---|
SSt-E250-KLx | SSt-Eclipse servo drive, 16A peak, 4A RMS, 24-90VDC, position-mode, panel-mount, cast L-bracket heatsink |
| ||
SSt-E252-KBx | SSt-Eclipse servo drive, 16A peak, 4A RMS, 24-90VDC, position-mode, board-mount |
| ||
SSt-E290-KLx | SSt-Eclipse servo drive, 20A peak, 6A RMS, 24-90VDC, position-mode, panel-mount, cast L-bracket heatsink |
| ||
SSt-E292-KBx | SSt-Eclipse servo drive, 20A peak, 6A RMS, 24-90VDC, position-mode, board-mount |
| ||
SSt-E350-RLx | SSt-Eclipse servo drive, 25A peak, 8A RMS, 24-90VDC, position-mode, panel-mount, cast L-bracket heatsink |
| ||
SSt-E352-RBx | SSt-Eclipse servo drive, 25A peak, 8A RMS, 24-90VDC, position-mode, board-mount |
| ||
SSt-E370-RLx | SSt-Eclipse servo drive, 30A peak, 10A RMS, 24-90VDC, position-mode, panel-mount, cast L-bracket heatsink |
| ||
SSt-E372-RBx | SSt-Eclipse servo drive, 30A peak, 10A RMS, 24-90VDC, position-mode, board-mount |
| ||
SSt-E427-KCx | SSt-Eclipse servo drive, 20A peak, 6A RMS, 24-90VDC, position-mode, panel-mount |
| ||
SSt-E490-KCx | SSt-Eclipse servo drive, 23A peak, 7A RMS, 24-90VDC, position-mode, panel-mount |
| ||
SSt-E520-RCx | SSt-Eclipse servo drive, 28A peak, 8A RMS, 24-90VDC, position-mode, panel-mount |
| ||
SSt-E545-RCx | SSt-Eclipse servo drive, 33A peak, 12A RMS, 24-90VDC, position-mode, panel-mount |
| ||
SSt-E600-KCx | SSt-Eclipse servo drive, 11A peak, 4A RMS, 100-400VDC, position-mode, panel-mount |
| ||
SSt-E610-KCx | SSt-Eclipse servo drive, 13A peak, 5A RMS, 100-400VDC, position-mode, panel-mount |
| ||
SSt-E720-RCx | SSt-Eclipse servo drive, 16A peak, 7A RMS, 100-400VDC, position-mode, panel-mount |
| ||
SSt-E730-RCx | SSt-Eclipse servo drive, 23A peak, 12A RMS, 100-400VDC, position-mode, panel-mount |
| ||
SSt-E750-RCx | SSt-Eclipse servo drive, 30A peak, 15A RMS, 100-400VDC, position-mode, panel-mount |
| ||
SSt-E760-RCx | SSt-Eclipse servo drive, 50A peak, 20A RMS, 100-400VDC, position-mode, panel-mount |
| ||
Model |
Description |
Photo |
Datasheet |
Price (100-pc/yr qty) |
|---|---|---|---|---|
SSt-E350-VLx | SSt-Eclipse servo drive, 25A peak, 8A RMS, 24-90VDC, analog velocity-mode, panel-mount, cast L-bracket heatsink |
| ||
SSt-E352-VBx | SSt-Eclipse Servo Drive, 25A Peak, 8A RMS, 24-90VDC, analog velocity-mode, board-mount |
| ||
SSt-E370-VLx | SSt-Eclipse servo drive, 30A peak, 10A RMS, 24-90VDC, analog velocity-mode, panel-mount, cast L-bracket heatsink |
| ||
SSt-E372-VBx | SSt-Eclipse Servo Drive, 30A Peak, 10A RMS, 24-90VDC, analog velocity-mode, board-mount |
| ||
SSt-E520-VCx | SSt-Eclipse servo drive, 28A peak, 8A RMS, 24-90VDC, analog velocity-mode, panel-mount |
| ||
SSt-E545-VCx | SSt-Eclipse servo drive, 33A peak, 12A RMS, 24-90VDC, analog velocity-mode, panel-mount |
| ||
SSt-E720-VCx | SSt-Eclipse servo drive, 16A peak, 7A RMS, 100-400VDC, analog velocity-mode, panel-mount |
| ||
SSt-E730-VCx | SSt-Eclipse servo drive, 23A peak, 12A RMS, 100-400VDC, analog velocity-mode, panel-mount |
| ||
SSt-E750-VCx | SSt-Eclipse servo drive, 30A peak, 15A RMS, 100-400VDC, analog velocity-mode, panel-mount |
| ||
SSt-E760-VCx | SSt-Eclipse servo drive, 50A peak, 20A RMS, 100-400VDC, analog velocity-mode, panel-mount |
| ||
Model |
Description |
Photo |
Datasheet |
Price (100-pc/yr qty) |
|---|---|---|---|---|
SSt-E350-YLx | SSt-Eclipse servo drive, 25A peak, 8A RMS, 24-90VDC, analog torque-mode, panel-mount, cast L-bracket heatsink |
| ||
SSt-E352-YBx | SSt-Eclipse Servo Drive, 25A Peak, 8A RMS, 24-90VDC, analog torque-mode, board-mount |
| ||
SSt-E370-YLx | SSt-Eclipse servo drive, 30A peak, 10A RMS, 24-90VDC, analog torque-mode, panel-mount, cast L-bracket heatsink |
| ||
SSt-E372-YBx | SSt-Eclipse Servo Drive, 30A Peak, 10A RMS, 24-90VDC, analog torque-mode, board-mount |
| ||
SSt-E520-YCx | SSt-Eclipse servo drive, 28A peak, 8A RMS, 24-90VDC, analog torque-mode, panel-mount |
| ||
SSt-E545-YCx | SSt-Eclipse servo drive, 33A peak, 12A RMS, 24-90VDC, analog torque-mode, panel-mount |
| ||
SSt-E720-YCx | SSt-Eclipse servo drive, 16A peak, 7A RMS, 100-400VDC, analog torque-mode, panel-mount |
| ||
SSt-E730-YCx | SSt-Eclipse servo drive, 23A peak, 12A RMS, 100-400VDC, analog torque-mode, panel-mount |
| ||
SSt-E750-YCx | SSt-Eclipse servo drive, 30A peak, 15A RMS, 100-400VDC, analog torque-mode, panel-mount |
| ||
SSt-E760-YCx | SSt-Eclipse servo drive, 50A peak, 20A RMS, 100-400VDC, analog torque-mode, panel-mount |
| ||
